NOMT: Nearly-Optimal Merkle Trie for SSD-era blockchain state

NOMT (“Nearly-Optimal Merkle Trie”) is a merklized, SSD-optimized key-value database designed to make state reads, updates, and proofs dramatically faster for blockchain nodes. This guide explains how NOMT works, why it matters, how it compares to sp-trie/JMT, and how to pilot it—plus pitfalls, FAQs, and SEO-ready metadata.

What problem does NOMT solve?

Modern L1/L2 nodes are increasingly I/O-bound, not CPU-bound. The slow part isn’t instruction execution; it’s fetching scattered state from disk and then merklizing it for proofs, light clients, bridges, or ZK circuits. NOMT targets this bottleneck by:

Reading from a flat key–value store during block execution (avoids trie walks on the hot path).
Batch-updating a page-aligned Merkle layout so proofs and new roots are cheap to compute and serve.

Why now? SSDs deliver high random IOPS in 4 KB pages. Classic tries force many tiny, random reads per access. NOMT packs multiple trie nodes into a single page so each disk hit yields more useful data, drastically cutting IOPS per operation.

ELI5: NOMT in one minute

Think of your blockchain’s state like a huge spreadsheet on an SSD. Every transaction needs to read scattered cells and prove the final sheet’s checksum (the Merkle root).

Old way: Walk a deep tree on disk—lots of page jumps just to read a few cells and compute a proof.
NOMT way:
- Keep an easy, flat index to read the cells during execution.
- Meanwhile, pre-fetch the tree pages you’ll need.
- Pack the tree so each SSD page contains a small subtree.
- While the SSD fetches, use the CPU to build proofs and stage updates.

Result: fewer disk trips, more work done between trips, faster roots & witnesses.

How NOMT works (design goals & mechanics)

Design goals:

Flat KV reads during execution. Avoid “walking the trie” on the hot path.
Aggressive prefetch. Saturate the SSD with parallel reads; hide I/O latency.
Do work while waiting. Generate witnesses and stage updates between page fetches.
SSD-page-aligned storage. Pack nodes so most reads are predictable and page-optimal.
Merklized, single-state database with multiproofs for large read/update batches.

On-disk layout insight: A 4 KB SSD page can hold a compact sub-trie (e.g., a small fixed-depth binary region plus metadata). NOMT implements this idea, decoupling logical structure from physical layout to minimize page reads per access.

Implementation status (POC → evolving):

Language: Rust.
Packaging: crates for the core and storage backends.
Intended use: Embeddable state DB for blockchain nodes; initial target included Sovereign-SDK.

Performance highlights & benchmarks

Public POC benchmarks (May 2024) on a Ryzen 7950X / 64 GB RAM / consumer 4 TB SSD (1 M IOPS), running 1,000,000 “transfer” ops over a 2^27 (~134 M)-account database, reported:

Mean workload (25k ops per batch): ~1,151 ms for NOMT vs ~12,530 ms (sp-trie) and ~17,075 ms (sov-db).
Mean commit+prove: ~431 ms (NOMT) vs ~874 ms (sp-trie) and ~16,144 ms (sov-db).
Peak SSD throughput ≈ 2.4 GiB/s (~618k IOPS) observed; the main bottleneck was state reads, not merklization.

Interpretation:

sp-trie incurs random-read penalties by traversing the trie on reads (Patricia-style).
sov-db/JMT separates KV & trie but faced higher I/O in that setup due to archival layout/column choices.
NOMT keeps execution on flat KV and performs trie updates/proofs off the hot path, leveraging prefetch and page packing.

Treat these as vendor-published POC numbers; reproduce on your hardware and workload before committing.

NOMT vs sp-trie vs JMT/sov-db (comparison)

Feature / DB	NOMT	sp-trie (Substrate)	JMT / sov-db (Sovereign)
Execution-path reads	Flat KV (no trie walks)	Trie traversal on reads	Flat KV + separate trie
Disk layout	SSD-page-packed sub-tries	Patricia/MPT-style	JMT optimized for LSM/LSM-like
Prefetch strategy	Aggressive parallelism	Limited by traversal	Impl-dependent
Proofs	Multi-proofs for batches	Patricia proofs	JMT proofs
Reported POC perf.	Fast; I/O-bound on reads	Slower random reads	Slower commit+prove (POC)
Maturity	POC; evolving crates	Battle-tested in Substrate	Active in Sovereign SDK

When to use NOMT

Choose NOMT if you need:

High-throughput block building/validation on SSD-backed nodes, where random state reads dominate cost.
Frequent multi-proof generation (light clients, bridges, ZK pipelines) without sacrificing execution speed.
A KV-first execution path with merklized state commitments updated off the hot path.

Prefer sp-trie/JMT if:

You rely on ecosystem-standard tooling tightly coupled to those tries.
Your workload is small state / heavy compute (I/O isn’t your bottleneck).
Operational risk of a new backend outweighs expected gains today.

Step-by-step: trial integration plan

Scope a canary node. Pick a non-critical validator/archive or a devnet sequencer.
Model your state access. Gather hot-path key distributions; estimate working set and page locality.
Bring in the crates. Add the NOMT core and a backend via a feature-flagged build; keep your canonical DB behind a clean interface.
KV adapter layer. Map runtime/storage keys to NOMT’s KV API; maintain parity with your current trie for cross-checks.
Prefetch hints. From your execution engine, emit read/write sets early so NOMT can pre-fetch pages while the block is still executing.
Witness integration. Wire multi-proofs into light-client/bridge flows; validate against golden vectors.
A/B benchmarks. Reproduce random-access stress and power-law distributions; vary batch sizes and I/O depth.
Operational hardening. Add backpressure, WALs/snapshots, page-cache tuning, and “panic to safe DB” toggles.
Rollout gates. Enable per-node; monitor: mean/95p state read latency, commit+prove time, IOPS utilization, CPU stalls.

Practical checklist

Confirm SSD health/specs (IOPS, queue depth, firmware).
Decide on KV key normalization (hashing, namespaces) for predictability.
Turn on I/O tracing (e.g., iostat, perf, blktrace) before/after.
Validate proof correctness (unit vectors + cross-implementation verifier).
Size page cache vs. RAM; test cold-start vs. warm cache runs.
Test pathological randomness and real power-law access.
Simulate reorgs and snapshot/restore flows.
Establish fallback to canonical state DB.

Common pitfalls & tips

“It’s still slow.” Ensure execution hits flat KV, not trie pages (no hidden trie walks on the hot path).
IOPS under-utilization. Increase parallelism (I/O depth, threads) until latency flattens; aim to saturate SSD queues.
Tiny batches. Multi-proofs shine with larger batches; very small blocks minimize advantage.
Misaligned pages. If backend/page size differs, you lose packing benefits; verify 4 KB (or device-native) alignment.
Unrealistic benchmarks. Avoid only-warm-cache runs. Clear OS page cache between rounds to mirror cold/warm scenarios.

FAQs

What exactly is “nearly-optimal” here? Minimizing page reads per access by packing trie nodes into SSD-sized pages; e.g., a small fixed-depth sub-trie fits in 4 KB, reducing random I/O.

Does NOMT replace my KV store? No. It embeds as a merklized KV backend; POCs use RocksDB-style storage underneath, with customized backends planned.

How does NOMT differ from Substrate’s sp-trie? sp-trie walks the trie for reads (Patricia-style), incurring more random I/O. NOMT reads flat KV during execution and updates the trie off the hot path.

How does NOMT differ from JMT (Diem/Aptos) and sov-db? JMT is optimized for LSM-based storage. In POC comparisons, sov-db showed slower commit+prove times than NOMT on the reported setup. Your mileage may vary—benchmark.

Is NOMT production-ready? Treat it as emerging—ideal for pilots and research. Check repo activity, issues, and tags; validate on your workload and hardware.

Can NOMT reach “Solana-level” throughput? It’s a directional claim: by removing merklization from the hot path and saturating SSD IOPS, nodes can approach similar throughput without dropping proofs—but real results depend on your execution engine and concurrency model.

Any related research after 2024? Yes—subsequent papers and surveys discuss SSD-aligned tries and fast state commitments, often referencing page-packing approaches.

Licensing? Permissive, open-source.

Conclusion

NOMT reframes state merklization for the SSD era: flat KV on the hot path, page-aligned sub-tries for low-IOPS proofs, and prefetch/parallelism to keep CPUs busy while disks work. If your node is I/O-bound, NOMT deserves a canary deployment and a fair A/B test against your current state DB.
